1. Performance of specimen frame lifting, limit space position, loading and off load can be finished during the lifting procedure.
2. Thanks to new material application and unique structure, the expansion coefficient of specimen frame has been controlled at the minimum value.
3. Dispersion of testing results for standard specimen is smaller than 0.5℃, even under the smallest load.
4. Automatic smoke exhaust system has been designed to guarantee the operator’s heath and not contaminate the environment.
5. Application of digital micrometer with communication interface brings the top class performance in mechanic & electronic controlling ability and software technology.
6. Temperature protective circuit, being independent from the controlling system, is designed to protect the tester when temperature of medium exceeds its using range.
7. Controlled by PC or touch screen, equipped with JINJIAN software to control test temperature and deformation, describe & record test curves, output testing result, save historical data as well as print out testing results, etc.
